Private AI Chat
Ask questions, draft content and solve problems using locally hosted models.
ENTRY-LEVEL PRIVATE AI PLATFORM
AI Starter Node
Private AI that gives your team useful answers from your own documents—without sending sensitive information to public AI services.
Private by design2U or 4U Supermicro applianceGrowth-ready GPU platform
BRAIN FARM USA AI STARTER NODE
PRIVATE AI
ON-PREMISES
ON-PREMISES
2U OR 4U SUPERMICRO GPU SUPERSERVER
WHAT IT DOES
A private AI system your team can actually use.
Document Intelligence
OCR, index, summarize and classify records, PDFs, scans and spreadsheets.
RAG Knowledge Search
Get answers grounded in approved company documents—with source references.
Business Automation
Turn internal information into secure analysis and practical daily workflows.
PRIVATE BY DESIGN
Your company data stays onsite. The AI reaches outside only when you allow it.
BrainFarm USA installs and configures an autonomous private AI platform on a server located inside your company. Your files, prompts, model responses, embeddings and RAG knowledge base remain within your company-controlled network instead of being uploaded to a public AI service.
On-Premises Intelligence
The AI models, company documents and knowledge base operate locally. Employees connect to the system through the company network, keeping sensitive information under company control.
Firewall-Controlled Internet Access
When current outside information is required, the AI makes an authorized outbound request through the company firewall. Security rules can limit websites, block sensitive content from outbound requests and log activity for review.
Approved RAG Expansion
The requested information returns to the private system. Once reviewed and approved, it can be indexed with its source and date so it becomes part of the company’s private RAG knowledge base.
The result: the company gains the usefulness of internet-connected AI without giving a public AI provider unrestricted access to its internal information. Internet retrieval and additions to the RAG knowledge base are governed by the company’s security and approval policies.
CAPABILITIES FOR A 1–25 PERSON BUSINESS
A capable private AI system for the whole company.
For a 1–25 person business, this is a very capable private AI system. It is best thought of as an in-office AI employee for the whole company—not a replacement for every cloud AI tool or a giant data-center system.
It would be very good for:
- A private company chatbot that answers questions from your manuals, policies, quotes, contracts, customer records, SOPs and past projects.
- Searching thousands of PDFs, scans, emails, spreadsheets and technical documents using plain English.
- Summarizing long documents, proposals, meeting notes, invoices and reports.
- Drafting emails, quotes, job descriptions, marketing copy, procedures and first-pass customer responses.
- Document OCR and classification—turning scanned paper files into searchable information.
- Creating separate knowledge areas for sales, operations, accounting, HR, engineering or service.
- Keeping sensitive company information on your own server instead of sending it to public AI websites.
- Supporting a few people working in it at the same time very comfortably; an entire 25-person office can use it as long as not everyone is doing heavy AI work simultaneously.
What the GPUs make possible
The 2× NVIDIA L4 GPUs give it 48GB of total GPU memory. That is strong for local business models—especially fast 7B–14B-class models and many larger models in optimized or quantized form. It is a good fit for private chat, RAG document search and day-to-day productivity.
It is not the right system for:
- Training a brand-new large AI model from scratch.
- Running the largest models at maximum speed for many users all at once.
- Heavy video generation, large-scale image generation or hundreds of simultaneous users.
- Replacing a large cloud data center.
The right balance for a small business
For most small businesses, that is actually the right balance: enough horsepower to be useful every day, without the cost, heat, power use and complexity of an 8-GPU H100 or A100 system. If usage grows, the planned path is to add L4 capacity first, then step up to L40S- or A100-class systems.
CURRENT-GENERATION DDR5 PLATFORMS
Same Day-One capability. Two DDR5 expansion envelopes.
Both systems begin with the same current-generation processors, DDR5 ECC memory, storage, networking, private AI software and 2× NVIDIA L4 GPUs. Choose the compact 2U platform for rack density, or the 4U platform when you want maximum power, cooling and in-chassis headroom for upgrading from the entry-level to mid-level and ultimately the high-end A100 configuration.
COMPACT DDR5 PLATFORM
2U AI Starter Node
Supermicro SYS-221H-TNR
PROCESSORS2× Intel Xeon Gold 5416S · 32 cores total
GPU2× NVIDIA L4 24GB · 48GB total
MEMORY512GB DDR5-4400 ECC RDIMM · 16× 32GB
OS STORAGE2× 1.92TB enterprise SSDs · mirrored
AI & DOCUMENT STORAGE4× 3.84TB enterprise SSDs
NETWORKINGDual-port 10GbE AIOM · 25GbE optional
POWER & COOLING2× 1200W redundant Titanium PSUs · 4 heavy-duty fans
EXPANSIONUp to 16 drive bays · up to 8 L4 or 4 double-width GPUs
2U IN-CHASSIS UPGRADE PATH
- Start2× L4 · 48GB GPU memory · 512GB DDR5
- Mid-level4× L4 · 96GB GPU memory · 1TB DDR5
- High-end2× A100 80GB PCIe · 160GB GPU memory · 1.5TB DDR5
Supermicro lists both L4 and A100 support for this DDR5 chassis, so the standard BrainFarm USA high-end conversion remains in the 2U system. The compact chassis has a tighter power and thermal envelope than the 4U platform.
MAXIMUM DDR5 / A100 HEADROOM
4U AI Starter Node
Supermicro SYS-421GE-TNRT3
PROCESSORS2× Intel Xeon Gold 5416S · 32 cores total
GPU2× NVIDIA L4 24GB · 48GB total
MEMORY512GB DDR5-4400 ECC RDIMM · 16× 32GB
OS STORAGE2× 1.92TB enterprise SSDs · mirrored
AI & DOCUMENT STORAGE4× 3.84TB enterprise SSDs
NETWORKINGDual-port 10GbE onboard · 25GbE optional
POWER & COOLING4× 2700W redundant Titanium PSUs · 8 heavy-duty fans
EXPANSION12 drive bays · up to 8 L4 or 8 double-width GPUs
4U IN-CHASSIS UPGRADE PATH
- Start2× L4 · 48GB GPU memory · 512GB DDR5
- Mid-level4× L4 · 96GB GPU memory · 1TB DDR5
- High-end2× A100 80GB PCIe · 160GB GPU memory · 1.5TB DDR5
Supermicro lists both L4 and A100 support for this DDR5 chassis. The high-end conversion stays in the same 4U system, with room for the planned 6× 7.68TB data-storage tier, 25GbE networking and additional engineered GPU expansion.
BrainFarm USA validation gate: GPU changes are engineered upgrades—not simple card swaps. Before shipment or conversion, we validate the exact risers, brackets, power cables, firmware, airflow, rack power and GPU qualification. The A100 configuration requires a validated 200–240V rack-power plan; this is especially important for the 2U system’s full-load power margin.
CONSULTING, TRAINING & LIFECYCLE SUPPORT
BrainFarm USA stays with you after installation.
This is more than a server purchase. BrainFarm USA helps your people use the system, develops and improves the private AI, maintains the hardware and supplies the components needed to expand capacity as your business grows.
Staff Consulting & Training
Role-based training for employees and administrators, including safe-use policies, prompt development, workflow design and hands-on instruction using your company’s actual business needs.
AI Training & RAG Development
We prepare and index approved company knowledge, refine prompts and retrieval rules, test answer quality and continue improving the AI and its RAG knowledge base as your business changes.
Monthly Hardware Maintenance
Available monthly service plans include scheduled system-health reviews, temperature, fan, memory, storage and GPU checks, preventive maintenance, firmware planning, issue diagnosis and capacity reviews.
Upgrade Parts, Trade-Ins & Engineering
BrainFarm USA supplies validated DDR5 ECC RAM, NVIDIA GPUs, enterprise SSDs and compatible installation hardware. When you upgrade, we will take eligible replaced parts in trade and apply their evaluated value as a discount toward the new parts.
WHY IT WORKS
Built for a useful first deployment—not a science project.
BrainFarm USA combines the server, private AI software, validation and deployment planning into one practical starting point. It is designed for organizations that want to see real value from private AI while maintaining control of their information.
Included in the BrainFarm approach
- Hardware configuration and validation
- Private AI platform setup
- Document-intelligence and RAG readiness
- Consulting, training and maintenance options
IS IT THE RIGHT FIT?
Designed for practical private AI—with a current DDR5 foundation.
What it is good for
- Small-team and department-level AI inference
- Secure internal knowledge search and RAG
- Document intelligence, summarization and embeddings
- Engineering, legal, operations and administrative workloads
- Organizations that need data to stay on-premises
What it is not designed for at launch
- Training very large foundation models from scratch
- Very high-concurrency, company-wide AI on the base 2× L4 configuration
- Workloads that require A100-class GPU memory before the planned upgrade
- Replacing a large multi-node AI cluster
- Public-cloud-scale GPU capacity on day one
2U DDR5 growth path
2× L4 → 4× L4 → 2× A100 80GB PCIe. The SYS-221H-TNR can reach the BrainFarm USA high-end A100 configuration without replacing the chassis. Choose it when a compact 2U footprint is the priority.
4U DDR5 growth path
2× L4 → 4× L4 → 2× A100 80GB PCIe. The SYS-421GE-TNRT3 reaches the same high-end target with substantially more power, airflow, storage and GPU headroom. Choose it when maximum long-term expansion is the priority.
READY TO START?
Let’s match the Starter Node to your team.
Tell us about your documents, users, security requirements and goals.
